| 型号 | 中心频率(MHz) | 通带带宽(MHz) | 插入损耗(dB)(max.) | 封装尺寸 |
| SF3222 | 337.4 | 12 | 32 | QCC12C |
| SF4176 | 435.0 | 12 | 70 | QCC8C |
| SF4206 | 455.4 | 12 | 31 | QCC12C |
| SF4010 | 480.0 | 18 | 18.00(3dB) | QCC8C |
| SF4053 | 480.0 | 18 |
18.00(3dB) |
TO39 |
| SF5124 | 512.2 | 12 | 30 | QCC12C |
| SF5126 | 514.25 | 13 | 28 | QCC12C |
| SF6115 | 690.5 | 30 | 6.8 | QCC12C |
| SF7132 | 720 | 17 | 126.00(3dB) | QCC8C |
| SF7134 | 720 | 12 | 1.5 | QCC12C |
| SF7135 | 720 | 11 | 2 | QCC12C |
| SF7136 | 720 | 11 | 3 | QCC12C |
| SF7137 | 720 | 13 | 8 | QCC12C |
| SF8133 | 899 | 33 | 24.00(3dB) | QCC12 |
